Air Receiver

Air Receiver

VSPV manufactures premium Static air receiver for air storage.in capacities from 25 KL to 55 KL .Thanks to our extensive range of diameters, the scope of possible tank sizes always allows storage capacity requirements to adapt to the characteristics of each project.

Static air receiver for air storage vertical and horizontal above ground installations, are made in accordance with European Directive 2014/68/UE and with CE marking. Upon request we can manufacture tanks to the regulatory requirements of the place of destination.

Our air receivers also known as air tanks or compressed air storage tanks are used across numerous industries like Manufacturing and assembly, food and beverage processing, pharmaceutical and medical, construction and mining, textile and paper industries, chemical processing, transportation.

Technical Specifications

Responsive VSPVAsia Table
Specification
Design Code:IS 2825, ASME Section VIII Div I and div II,
Tank TypeVertical/Horizontal
Design Pressure15.4 kg/cm² + static head
Design TemperatureMin 0°C / Max 55°C
Working Pressure14 bar
Corrosion Allowance1.5 mm
Dish EndTorispherical, Ellipsoidal
Support Type Saddle /Skirt/Leg
External FinishSand blasting as per SA 2.5 and painting as per customer request
Design Lifetime15+ years with proper maintenance

All our tanks can be customized with components thermal SRV for safety,  pressure gauge and transmitter, level gauge and transmitter, high level alarm or switch.

Our Storage tanks comply with international safety and quality guidelines

Every VSPV storage tank undergoes comprehensive testing

VSPV stands behind our products throughout their service life:

1-year warranty on manufacturing defects

Contact VSPV today for detailed specifications and customization options to meet your storage requirements.

Questions? You’re covered

At vero eos et accusamus et iusto odio dignissimos ducimus qui blanditiis praesentium voluptatum deleniti atque corrupti quos dolores et quas molestias excepturi sint occaecati cupiditate.
01. Can i use green energy in my home or business?
Randomised words which don’t look even slightly believable. If you are going passage of you need sure there anything make a type specimen book. It has survived not only five centuries.

Randomised words which don’t look even slightly believable. If you are going passage of you need sure there anything make a type specimen book. It has survived not only five centuries.

Randomised words which don’t look even slightly believable. If you are going passage of you need sure there anything make a type specimen book. It has survived not only five centuries.

Main Features
01

Robust Design

Manufactured with corrosion resistant stainless-steel (SS) plate, stainless steel (SS) seamless pipe, high quality valves, gauges and instruments.
02

SS Seamless Pipes and Tubes

VSPV uses only corrosion resistant stainless-steel pipes and tubes for inner tank piping and external piping to have a better aesthetics, long corrosion free, leak free and maintenance free life.
03

Oxygen Compatible Cleaning

Stainless steel inner tank, internal pipes, external pipes, and fittings are cleaned through a series of processes like pickling, passivation and degreasing followed by stringent quality checks with a ultraviolet (UV) lamp, which ensures superior clean environment for Oxygen storage.
04

Testing

Tanks undergo through a series of Non-Destructive Examinations (NDE) including helium leak test to ensure robustness, long vacuum retention, leak proof and maintenance free life.
05

Vacuum Guarantee

Stringent helium leak test, followed by Vacuuming with latest good quality vacuum pumps provides a long vacuum retention period.
06

Quality Components

VSPV uses very quality time-tested cryogenic valves, safety relief valves, regulator, Thermal Relief Valves, 3-way Divertor valve, Level & Pressure gauge.
07

Painting & Aesthetics

Steel grit blasting to SA 2 ½ followed by a 3-coat painting process Provides resistance to corrosion, oxidation, and better aesthetics for long-term.
08

Flexibility

Customer can choose between perlite & super insulation or 4-Leg & 3-Leg design
09

PESO Approval & Site Work

VSPV is well equipped for site civil foundation work, erection & commissioning, and support for PESO approval & licensing
