V.S. Pressure Vessel and Gas Projects Pvt. Ltd. (VSPV) designs & manufactures superior quality Cryogenic liquid standard (Std.) storage tanks for Liquid Nitrogen (LIN), Liquid Oxygen (LOX), Liquid Argon (LAR), Liquid Carbon Dioxide (LCO2) and Liquid Nitrous Oxide (LN2O). Tanks are vacuum insulated with the option of either Perlite or Multi-Layer super Insulation
VSPV std. cryogenic tanks are designed to offer our customers the ease of operation, low evaporation loss, leading to low operation cost. With a robust design using the austenitic stainless-steel plates, seamless stainless-steel pipes, world renowned imported quality valves, gauges & instruments. Tank size ranges from 3,000 litres to 60,000 litres, with maximum allowable working pressure (MAWP) of 17.2 bar, 23 bar or 37 bar. Tanks are designed according to EN-13458 / ASME Section VIII Div 1 as per the customer requirement.
Technical Specifications
| Specification | Value |
|---|---|
| Design Code: | EN-13548, ASME section VIII Div I and other design codes |
| Service Type: | LIN, LOX, LAR, LCO2 |
| Tank Type | Vertical/Horizontal |
| MOC | Inner Vessel: SS 304, Outer Vessel: IS2062/SA 516 |
| MAWP | 17.2 bar, 23 bar, 37 bar |
| Design Temperature | Min - 196°C to Max 50°C |
| Insulation | MLI + Vacuum / Perlite + Vacuum |
| Dish End: | Torispherical |
| Support Type: | Saddle / Leg |
| External Finish | Polyurethine epoxy paint(white) |
| Design Lifetime: | 15+ years with proper maintenance |
