LPG Propane 990 Litres Water Capacity Cylinders

VSPV > LPG/Propane Storage Solutions > LPG Propane 990 Litres Water Capacity Cylinders

LPG/Propane 990 Litres Water Capacity Cylinders

VSPV manufactures premium LPG/Propane storage cylinders sized at 990 L capacity. Our 990L premium quality cylinders are used in various industrial and commercial applications across the country;. such as

  • Industrial Processing: Provides consistent heat source for chemical manufacturing
  • Commercial Cooking: Supplies multiple commercial kitchen appliances simultaneously
  • Agricultural Drying: Powers crop drying systems during harvest seasons
  • Emergency Power: Fuel source for standby generators and backup systems
  • Fleet Refueling: Central storage for forklift and vehicle fleets
  • Vaporization Rate: Up to 60kg/hour at 15°C ambient temperature
  • Multi-Tank Configurations: Engineered manifold systems for expanded capacity requirements

Technical Specifications

  • Design Code: EN-13445
  • Dimensions: : 2750mm length × 950mm diameter (standard configuration)
  • Tare Weight: 652kg ±5kg (for LPG) and 760KG (for Propane) , optimized for stability while maintaining mobility
  • Emergency Power: Fuel source for standby generators and backup systems
  • Working Pressure: 14 bar (propane) 7 bar (lpg) exceeding industry standards
  • Test Pressure: all our cylinders are hydro tested as per safety standards
  • Storage Capacity: Approximately 425kg of LPG/Propane at 85% fill ratio
  • Design Lifetime 25+ years with proper maintenance
  • High-performance epoxy primer base (120μm thickness)
  • UV-resistant polyurethane topcoat (80μm thickness)
All our cylinders come with components SRV for safety, multi valve for filling and withdrawal, level gauge: for checking liquid levels, drain and safety features like
  • Pressure Relief Valves: Calibrated to 25 bar, with 120% flow capacity
  • Excess Flow Protection: Automatic shutoff valves that activate at 125% of rated flow
  • Magnetic Level Indicators: Precision measurement without mechanical failure points
  • Anti-sloshing Baffles: Internal stabilizers for safety during transportation and reduced structural stress
  • Fire Protection Rating: 4-hour minimum time-to-failure under direct flame exposure
  • Double Check Valves: To prevent backflow and cross-contamination
Our cylinders comply with international safety and quality guidelines
  • ISO 9001:2015: Certified quality management system
  • PED: Pressure Equipment Directive compliance
  • Third-Party Verification: Each vessel inspected and certified by TÜV/Lloyd's Register

Comprehensive Safety Features

Our LPG/Propane cylinders comply with all relevant industry standards and safety regulations, with pressure ratings suitable for storing propane and butane mixtures at ambient temperatures.

Every VSPV cylinder undergoes comprehensive testing

  • Precision heat treatment, ensuring optimal metallurgical properties and structural integrity. Normalized cooling process eliminates internal stresses, enhancing long-term reliability and resistance to pressure cycling.
  • Hydrostatic pressure testing at 1.5× working pressure
  • Burst testing on sample units to verify 3× safety margin
  • X-ray inspection of critical welds
  • Ultrasonic wall thickness verification

All our cylinders are PESO approved and comply to the Gas cylinder rules. VSPV stands behind our products throughout their service life.

  • 5-year warranty on manufacturing defects
  • Scheduled maintenance programs (AMC)

Contact VSPV today for detailed specifications and customization options to meet your specific LPG storage requirements.
